X-Vision Handheld Portable X-Ray (Special VIP Pricing)

FLIGHT DENTAL SYSTEMS

The Flight X-Vision Portable Handheld X-Ray is an ultra-safe state of the art system that has lower radiation levels than your traditional wall mounted x-rays. In addition, the ergonomic design allows the x-ray to be comfortably held in your hands and with one of the most intuitive and easy to use interfaces it makes doing a full mouth series even faster and more efficient. The X-Vision features the longest battery life on the market,  with a full charge, it is able to take up to 800 shots with very low exposure times while producing the best quality images whether it’s on film, digital sensor or phosphorus plates. Finally, with the use of high quality components, from the Panasonic battery to the Toshiba tube head, made in Japan, the X-Vision is the workhorse X-Ray for every office.

  • Easy to learn and use
  • Includes neck strap
  • 1 year warranty, extendable to 5 years
  • Pre-set settings to avoid any unnecessary manipulation of parameters needed to generate X-Rays
  • Largest battery capacity on the market of any handheld X-Ray
  • 2900 mAh battery allows for over 800+ exposures before needing to charge (40+ patient’s full mouth series)
  • >1.6 mm total Aluminum filtration leads to the very low amounts of leakage radiation of any handheld device
  • Oiled cooling allows for less refractory time between exposures
Categories: ,

Description

The Flight X-Vision Handheld Portable X-Ray system is a state of the art x-ray generator that can be used in an array of settings. This easy to use, light weight and ergonomic X-Ray system offers the longest battery capacity on the market, with up to 800 exposures on a single charge. The camera type portable x-ray comes with a neck strap and hand straps to prevent falls and accidental damages. In addition, the convenient location of the x-ray activation switch allows you to quickly and easily take a full mouth series much quicker and with less re-takes than your traditional wall mount x-ray. This is the portable x-ray that every dental offices needs to have to improve workflow and efficiency.

Handheld X-Ray Wall Mounted X-Ray
  • No Installation
  • Portable
  • Cordless
  • Remaining in the room allows you to control patient’s movement and skillfully take pictures at any desired position due to its mobility (less retakes needed)
  • Less radiation per exposure
  • Only one unit needed per clinic
Mounting Block Needed
Stationary
Outlet needed
Limited control on how to angle and take pictures. The wall mount can sway causing blurry images
Higher tube current leads to greater exposure of radiation for the same clarity of images
Limited to one unit per operatory

SAFETY

  • Double Shielding from X-Ray Radiation
  • Lead Shielding around Generator + Back Scatter Shield
  • No Significant radiation exposure measured at 10mm distance from device
  • FDA requires all X-Ray devices to not exceed 0.25mgy/hr. X-Vision only has 0.04 mgy/hr of leaking radiation, making the X-Vision 6.25x more stringest than the FDA recommended guidelines

X-Vision Brochure

X-Vision Presentation

X-Vision Radiation Survey

SPECIFICATIONS

Flight Dental System’s

X-Vision

Vector Maxray KaVo Nomad Pro 2 Vatech EzRay Air GenoRay

Port-X  IV

Digital Doc XTG Denterprise

MobileX

Midmark Preva
Tube Voltage 60 kV 65 kV 60 kV 65 kV 70 kV 60 kV 70 kV 60-70 kV
Tube Current 2.0 mA 1.7 mA 2.5 mA 2.5 mA 2.0 mA 2.0 mA 2.0 mA 4-7 mA
Exposure Time Range 0.02-2.0 s 0.05-1.35 s 0.02-1.0 s 0.05-1.0 s 0.5 s 0.01-1.0 s 0.01-2.0 s 0.01-2.0 s
Battery Life (Exposures) 2900 mAh

(800 exposures)

1050 mAh

(250 exposures)

2400mAh

(600 exposures)

2500 mAh

(400 exposures)

1000 mAh

(300 exposures)

1000 mAh

(350 expsures)

Minimum  150 Exposures N/A
Weight 6.8 lbs 6 lbs 6 lbs 5 lbs 3.5 lbs 5.3 lbs 4.7 lbs N/A
Total Filtration >1.6 mmAI (Inherent Filtration: 0.8 mmAl, Fixed added filter: 0.7 mmAl) >1.5 mmAI equivalent 1.5 mmAI minimum Inherent Filtration: 0.8 mm Al, Fixed Added Filtration: 1.0 mm Al 1.7 mm AI
Warranty 1 Year 12 months Limited Warranty 12 Month Warranty covering repairs and overnight Loaner 2 year Limited Warranty 2 Years Parts Warranty 90 day Parts and Labor Warranty then Repair warranty for 2 years 1 Year 2 years
